| Optical Parameters | Unit | Min. | Typ. | Max. |
| Output Power | W | 480 | ||
| Center Wavelength2@41A | nm | 970.5 | 974.5 | |
| Spectral Width(FWHM) | nm | 6 | ||
| Power Within NA | NA | 0.18 | ||
| Back Reflection Isolation Range | nm | 1040 | 1064 | 1200 |
| Back Reflection Isolation | dB | 30 | ||
| Fiber Core Diameter | μm | 217 | 220 | 223 |
| Fiber Clad Diameter | μm | 240 | 242 | 244 |
| Core Numerical Aperture | NA | 0.21 | 0.22 | 0.23 |
| Fiber Length2 | m | 1.5 | 2.0 | |
| Loose Tubing Diameter | mm | 1.1 | 1.4 | |
| Loose Tubing length | m | 1.2 | 1.5 | |
| Fiber Connector | Bare Fiber/SC Ceramic Ferrule | |||
| Fiber Bend Radius | mm | 65 | ||
| Conversion Efficiency | % | 48 | ||
| Threshold Current | A | 2.1 | ||
| Operating Current3 | A | 41.0 | ||
| Operating Voltage3 | V | 24.0 | ||
| Operating Temperature Range4 | ℃ | 5 | 45 | |
| Package Temperature Range1,4 | ℃ | 45 | ||
| Lid Temperature Range1 | ℃ | 60 | ||
| Boot and Fiber Temperature1 | ℃ | 45 | ||
| Storage Temperature Range | ℃ | -30 | 85 | |
| Wavelength Temperature Coefficient | nm/℃ | 0.35 | ||
| Lead Soldering Temperature | ℃ | 260 | 300 | |
| Lead Soldering Time | s | 10 |
