Robotic Systems for Laser Cutting
Video Thumbnail
Video Thumbnail
Video Thumbnail
Video Thumbnail
Video Thumbnail
Video Thumbnail

CINA Laser 6-Axis 3D laser cutting robot can cut non-standard shape material. It can be six axis feed and is able to cut from 360 degree. Moreover, some non-standard materials, such as some with fixed geometry and angle, can also be cut by it.
The production flexibility, versatility and convenience of 6-Axis cutting allows you to innovate and develop new technological and design solutions.
Ideal to access new industrial sectors and be immediately competitive.
It uses the FANUC robot arms and FANUC operating system imported from Japan, making it convenient to use.
Large processing area. The maximum working radius of six-axis is 2010mm.
Equipped with a gantry which can expand the processing space and ensure the flexibility of cutting head.
There are various irregular shape materials for processing automotive sheet metal, 3d kitchen ware and sports equipment. General fiber laser cutting machine can not achieve the precise processing of irregular materials, but CINA Laser 6-Axis 3D laser cutting robot can play well in these industries.
Technical Index
Performance Unit Supplement
· Robot Brand   FANUC
· Robot Model
Controlled Axes   6
Fiber Laser Source Power W 1000 1500 2000 ( optional)
Max Payload kg 25
Reach mm 1853
Repeatability mm ±0.02
Installation   Floor stand /Hang upside down /Wall mounted

Model Explanation
