CYL/H 1kW~3kW

1.0μm Single-Mode (Highly Reflective Metals) Continuous Fiber Laser
Video Thumbnail
Video Thumbnail
Video Thumbnail
Video Thumbnail
Video Thumbnail
Video Thumbnail

Description
CINA Laser CYL/H series high-brightness anti-high reflective single-mode 1.0μm continuous fiber laser, adopts latest industry technology and the optimization design, with high electro-optical conversion efficiency, high lifetime, high safety and reliability. The unit with high-quality output beam and strong capability on resisting high-reflective, can be widely used in all kinds of materials of laser cutting, welding, punching, 3D printing and other high-end smart manufacturing.

Features
 High electro-optic conversion efficiency, greatly reduce power consumption.
 Strong anti-high reflection ability, suitable for different material processing.
 Remote real-time monitoring.
 High lifetime, high safety and reliability.
 Can be personalized customization
 Excellent after-sales service system
 Excellent cost performance
Applications
 Laser cutting
 Laser welding
 Laser cladding
 Laser brazing
 Laser thermolizing
Size
Series
Technical Index
Performance Min. Typ. Max. Remarks
Optic Feature Central wavelength (nm) 1070 1080 1090
Spectral bandwidth (nm)   3 5 -3dB
Output optical power CYL-1000/H (W)   1000
CYL-1500/H   1500
CYL-2000/H   2000
CYL-3000/H   3000
Short-term power stability (%) ±1
Long-term power stability (%) ±2
Laser turn-on time (μs) 50~100
Laser off time (μs) 100~200
Power adjustment range (%) 10   100
Beam quality (M2)     1.3 QBH-25/400
Modulation frequency (KHz) 5   20 100% output
Red light power (mW) 5   60
Output Feature Output connector     QBH   Customizable
Output fiber core-diameter (μm)   25
Output fiber length (m)   15   Customizable
Output fiber bending radius (mm) 200
Work mode   Continuous / modulation CW/Modulate
State of polarization   Random Random
Electrical cooling Feature Communication interface   RS232 / AD / Super terminal
Remote telecommunication   APP Customizable
Power supply (V)   220
Power consumption CYL-1000/H (KW)     3.0 Single-phase three-wire
CYL-1500/H     4.5
CYL-2000/H     6.0 Two sets 220V
CYL-3000/H     8.5
Cooling mode   Water cooling Circumscribed
Coolant temperature (°C) 20   28
Coolant flow     CYL-1000/H (L/min)   10


CYL-1500/H   20
CYL-2000/H   25
CYL-3000/H     40
General Feature Working environment temperature (°C) 10   40
Working environment humidity (%) 10   85
Storage temperature (°C) -10   60
Structure   Rack
Weight/Size CYL-1000/H (kg) 38 (W) × (L)(contain the handles) × (H)(mm) 486.2(440)×451×104
CYL-1500/H 40 486.2(440)×451×104
CYL-2000/H 43.4 486.2(440)×596×111
CYL-3000/H 53 486.2(440)×666×111


Model Explanation
